Lightweight&Portable outstanding performance
Full-scenario oprated by intelligent
Quick installation
Modular installation of obstacle avoidance radar, terrain-following radar and camera
Extremely spacious interior
The interior of the front hood is spacious,easy to install cables.
Press-type locking design
Press-type locking design,double safety,
The body is designed to be waterproof and dustproof
Sealed structure designe, effectively
achieving waterproof and dustproof, ensuring the safe operation of the internal circuits.
- Efficient and precise flow control, intelligent centrifugal nozzles, controllable droplet size,
- capable of adjusting to the optimal flow andatomization effect according to
- different crops and pesticide types, achieving precise spraying.
5-8m
Effective spray range
5L/min
Spraying flow
50mu
Time-sensitive operation
Aluminum alloy frame
Aluminum alloy frame,more lightweight,
more strength,less deformation or fracture, and higher resistant to pressure.
Centrifugal nozzles
The more atomization uniformity and more flow rate adaptation range
Brand new design of pestcide tank
The water gun can be used to refill pestcide,significantly enhancing work efficiency
Brushless water pump
The preferred solution for efficient and highly reliable fluid transmission, specilize for long lifespan, low noise, small size, energy conservation and environmental protection, or intelligent control of application scenarios.
SPREADING SYSTEM
- The umbrella-shaped metal structure,wide force-bearing area and no blocking the material.
- The rotating disc is metal materials, which enhances the strength, more sturdy and resistant to pressure, and also more wear-resistant
Obstacle avoidance radar
detect obstacles andachieve autonomous obstacle avoidance
Terrain radar
The terrain radar keeps the relative altitude of the aircraft unchanged according to the terrain.
FPV Camera with LED light
Front-mounted FPV camera, 120° wide-angle lens, clearly presenting the front scene on the remote control
- X9 plus II It builds upon the original foundation with overall performance enhancements, longer battery life, quicker response times, and greater stability.
Flight control system, multiple choices
K++ or V9 FC both can be installed,adapt to your individual needs.
- Utilizing advanced SDR technology and a super protocol stack. video transmission, serial port, and s.bus port include, with waterproof, dustproof, and shockproof materials and structures.
SMART BATTERY
Large capacity super endurance
Large-capacity battery with super long endurance and support for fast charging
- 14S 20000mah
- Due to differences in configuration, there may be slight variations. Please refer to the actual product for details.
SPECIFICATION
The product dimensions, weight, battery capacity, etc.
may vary slightly due to configuration differences. Please refer to the actual product for details.
Basic Specification:
|
Unfolded size |
1370*1300*665mm |
Folded size |
800*665*670mm |
|
Wheel base |
1700mm |
Load |
20L |
|
Weight of frame |
19kg(exclude motor&battery) |
Take-Off weight |
50kg |
|
Granule capacity |
40L |
Material |
PE,PP,PA+GF,al alloy |
Flight Specification:
|
Battery capacity |
14S 20000mah |
Operating voltage |
58.8V(14S) |
|
Rising speed |
5m/s |
speed |
5-10m/s |
|
No-load endurance |
18min |
Full load endurance |
8min |
Spray Specification:
|
Nozzle |
Centrifugal Nozzel |
Spray width |
5-8m |
|
Flow Rate |
5L/min |
Efficiency |
50mu |
Packing Specification：
|
Rack case size |
830*540*370mm |
Rack case weight |
10.2kg |
|
Powerbox size |
625*375*290mm |
Powerbox weight |
9.4kg |
|
Medicine box size |
460*350*410mm |
Medicine box weight |
3kg |
|
Spread box size |
595*350*415mm |
Spread weight |
3kg |
|
Full chassis size |
830*700*755mm |
Full chassis weight |
30kg |
